KOHLER PW 5000/TP

KOHLER PW 5000/TP

10-50kVA, Three-Phase, Standalone

Ideal for: mid-size server rooms, networks, telecommunications systems, and life safety applications

Standalone three-phase UPS system available in seven power ratings from 10 to 50kVA and in different cabinet sizes enabling you to choose a compact system with the ideal internal battery capacity for your critical load. A true online, double conversion, VFI (voltage frequency independent) UPS system that offers exceptional reliability and unprecedented power availability for mid-size server rooms, networks, telecommunication systems and industrial processes.

  • Compact UPS power supply system with intelligent battery management
  • 5% efficiency and a low carbon footprint
  • Parallel capability of up to 20 units.

More Information

Compact UPS power supply system with intelligent battery management, 95.5% efficiency and a low carbon footprint. Delivers excellent value for money without compromising on performance.

Highest load availability

Redundant critical circuits (RCC) duplicate the critical components and circuitry within the KOHLER PW 5000/TP to maximise productivity and minimise downtime.

Low lifetime cost

Innovative transformerless design and Energy Saving Inverter Switching (ESIS) technology ensures high efficiency to reduce the total cost of ownership. Temperature controlled battery chargers extend lifetime performance to reduce running costs.

Small footprint to save space

Compact design maximises floor space with a footprint of 0.4m2 at 50kVA. A power density of up to 100kW/m2 saves space for other IT equipment.

Flexible battery configuration

Available in three cabinet sizes, the three-phase uninterrupted power supply offers flexible capacity for critical loads. The 10 to 25kVA units are available in two cabinet sizes and the 30 – 50kVA units are housed in a larger cabinet to accommodate different configurations of internal batteries.

Additional battery cabinets that match perfectly with the UPS for scaling autonomy time.

95.5% energy efficiency

Designed with state-of-the-art energy efficiency of up to 95.5%, the KOHLER PW 5000/TP helps to reduce carbon footprint and running costs.

To request more details about the KOHLER PW 5000/TP make an enquiry using the form below or call us on +65 6302 0702.

Technical Specification

Actual kVA 10-50kVA
Type Three-phase
Standalone / Modular Standalone
Max. power per frame with N+1 redundancy Up to 20kVA N+1
Parallelable up to 20 units (1MVA)
Rated output voltage range 380/220; 400/230; 415/240V three-phase
Working mode Online double conversion
Power density per m2 Up to 112kWm2 / 125kVA/m2
Battery compartment Included in UPS cabinet
Maintenance bypass Standard
Network/web interface Option
Volt free contacts Standard
Input current distortion THDi @100% load < 3%
Scalable (N+1) Yes (horizontal)
Hot-swappable modules No
